Industrial high temperature continuous heat treatment high-purity
alumina powder sintering roller hearth furnace
Roller hearth furnaces are built with two openings opposite each
other to allow items to pass into, through and out of the furnace
while moving in one direction. Depending on their application and
operating temperature they may contain either a conveyor belt or furnace rollers for the movement of items through the furnace. Various heating
methods are available, including gas-fire and resistive heating.
1﹑Applicable Material
Lithium battery materials, advanced ceramic materials, high-purity
alumina powder, catalysts, magnetic materials, rare earth materials
2﹑Technical Specification
| MAX temperature | 1350℃ |
| Working temperature | 1300℃ |
| Roller material | silicon carbide or alumina ceramics. |
| Chamber size | customized according to customer |
| Arrangement | 4 columns and 2 layers,4 columns and 1 layers,3columns and 2
layers, etc |
| Heating element | Silicon carbide rod or high temperature resistance wire |
| Heating method | horizontal heating |
3﹑Advantage
1. built with new refractory materials, arched structure on top,
which has a long service life and uniform exhaust.
2.with excellent thermal efficiency, and the uniformity of
temperature field can reach ±5°C.
3.Special intake and exhaust structure design can ensure
unobstructed exhaust during glue removal.
4.equipped with partition beams inside the Chamber, which can
adjust and control the atmosphere and supply in each temperature
zone.
5.Can be completely customized according to the actual process and
requirements of customers.
4﹑Patent
With proven engineering knowledge and more than 20 years'
experience we can provide you the right furnace solution.
5﹑Customer Case in China
The first Mobile phone fast charging graphene heat dissipation film
carbonization production line in china
The first ITO target powder roller furnace continuous production
line in china
6﹑Foreign Customer
7﹑Package and shipment
We will well pack the goods based on the kinds of furnace and
customer's requirement.
