    Two Temperature Zone Horizontal Quartz Tube Rotary Furnace High Temperature

    Ask Lasest Price
    Brand Name : QIANJIN
    Model Number : RF
    Certification : ISO9001
    Price : Negotiable
    Supply Ability : 100PCS/month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Two Temperature Zone Horizontal Quartz Tube Rotary Furnace High Temperature


    High temperature two temperature zone horizontal Quartz tube Rotary furnace

    A rotary furnace is a barrel-shaped instrument that is rotated around its axis when performing heat treatment. These instruments are tilted slightly to allow the sample under heat treatment to be passed from one end of the barrel to the other. This sample transfer occurs as the rotary furnace rotates, and this rotation can also induce some mixing or stirring of the sample.

    Two Temperature Zone Horizontal Quartz Tube Rotary Furnace High Temperature

    1﹑Technical specification
    Furnace tube materialQuartz tube
    Furnace tube sizeOuter diameter 60/80/100mm
    Heating elementResistance wire
    Max Temperature1200°C
    Frequency constant temperature<1160°C
    Temperature controlPID automatic control, 30-51 segment program temperature control
    Building heating/cooling rate5 C/min
    Constant temperature zone length200m
    Temperature accuracy±°C
    Power supply, single phase220VAC, 50/60Hz
    Volume550*2450*2670mm
    Weight60 Kg , (90kg with package)
    WarrantyOne year warranty on electrical and mechanical parts, excluding heating elements and quartz tubes.

    2﹑Advantage

    1.Resistance wire heating

    2.Quartz tube

    3.1200C advanced lining

    4.PID automatic control, 30-51 segment program temperature control system, effectively increase the free operation space of customers.

    5.High quality Type B thermocouple

    6.The stylish and simple control system greatly reduces the workload of the operator on the basis of ensuring accurate operation

    7.Can pass the atmosphere, vacuumize

    8.The human-oriented double-layer protection design effectively reduces the surface temperature of the protection and avoids injury to the operator

    9.There is an air cooling system between the double-layer furnace shells

    10.Energy saving (energy saving effect is 80% of the old electric furnace), uniform furnace temperature, good heat preservation effect, light weight


    3﹑Patent

    With proven engineering knowledge and more than 20 years' experience we can provide you the right furnace solution.


    4﹑Customer Case in China


    The first Mobile phone fast charging graphene heat dissipation film carbonization production line


    The first ITO target powder roller furnace continuous production line in china


    5﹑Foreign Customer


    6﹑Package and shipment

    We will well pack the goods based on the kinds of furnace and customer's requirement.
